High Accuracy Proline Prowirl F 200 by Endress Hauser Vortex Flow Meter for Process Control

The Proline Prowirl F 200 is a multivariable vortex flowmeter that measures volume flow, mass flow, temperature, and pressure in one device. It excels in steam and gas applications where direct mass flow output reduces installation cost and complexity. The rugged all-welded design and Heartbeat verification make it a favorite for long-term reliability in industrial utilities.

• Direct mass flow output for saturated steam
• Multivariable measurement – flow + temperature + pressure
• All-welded, gasket-free meter body
• Heartbeat Technology – in-situ verification
• Bluetooth configuration via SmartBlue app
• Optional integrated pressure sensor
• High turndown ratio

• Measuring Principle: Vortex shedding
• Max Measured Error: ±0.75% (liquids), ±1% (gas/steam)
• Measuring Range: Size-dependent (e.g. DN50: ~5–100 m³/h steam)
• Process Temperature: –40 to +260 °C standard; up to +400 °C optional
• Process Pressure: Up to 100 bar
• Line Sizes: DN15–DN300 (½"–12")
• Output: 4–20 mA HART, Pulse, Frequency, Modbus
• Approvals: SIL 2, PED, ATEX, IECEx

• Steam consumption measurement
• Boiler efficiency monitoring
• Compressed air distribution
• Natural gas and process gases

Q: Does it compensate for steam density? A: Yes – multivariable version gives direct mass flow.

Q: Verification without shutdown? A: Yes – Heartbeat Technology.
