Industrie applicabili: | Hotel, negozi dell'indumento, negozi di materiale da costruzione, officine riparazioni del macchinar | Posizione della sala d'esposizione: | Il Canada, Italia, Francia, Germania, Vietnam, Brasile, Messico, Spagna, Colombia |
---|---|---|---|
Video uscente-ispezione: | Fornito | Relazione sull'esperimento del macchinario: | Fornito |
Tipo commercializzante: | Nuovo prodotto 2020 | Garanzia delle componenti del centro: | 1 anno |
Componenti del centro: | Motore | Peso: | 32 kg |
Garanzia: | 1 anno | Peso (chilogrammi): | 32 kg |
Numero delle asce: | 6 | Carico utile massimo del polso (chilogrammi): | 5 chilogrammi |
Portata orizzontale massima (millimetri): | 809 millimetri | Ripetibilità (millimetri): | 0,03 millimetri |
Flangia di fissaggio dello strumento: | Iso 9409-1-A25 | Peso del robot (chilogrammi): | 32 kg |
Classe di protezione: | IP54 | Posizione di montaggio: | Pavimento/soffitto/parete |
Coppia di torsione sull'asse 6 (nanometro): | 4,91 nanometro | Colpo (velocità) sull'asse 6: | +/- 2700° (800°/s) |
Porto: | Shanghai |
item | value |
Applicable Industries | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company |
Showroom Location | Canada, Italy, France, Germany, Viet Nam, Brazil, Mexico, Spain, Colombia |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Marketing Type | New Product 2020 |
Warranty of core components | 1 Year |
Core Components | Motor |
Place of Origin | China |
Brand Name | Comau |
Weight | 32kg |
Warranty | 1 Year |
Weight (KG) | 32kg |
Number of axes | 6 |
Maximum wrist payload (Kg) | 5 kg |
Maximum horizontal reach (mm) | 809 mm |
Repeatability (mm) | 0.03 mm |
Tool coupling flange | ISO 9409-1-A25 |
Robot weight (Kg) | 32 kg |
Protection class | IP54 |
Mounting position | Floor / Ceiling / Wall |
Torque on axis 6 (Nm) | 4.91 Nm |
Stroke (Speed) on Axis 6 | +/- 2700° (800°/s) |
